CNC Turning centers with max turning diameter 750mm, max. turning length from 2m to 6m

- NewMachines.NET

TT 75

Multifunctional lathe center TOS Turn is production machine for fully automatic (semi-automatic) machining of shaft and flange components in optimal machining time with very high accuracy. Machine TT 75 features possibility to use most modern tools in the area of turning, milling and other technological operations built upon high support of CNC system yet from the workpiece clamping into the machine. Complex design nods are solved by most modern calculating methods simulating most realistically the machining environment. Robust bed ensures high rigidity of the machine needed for both exact and power machining in two spindles and independent rests.

All slide rests are fitted with longitudinal and traverse feed, main slide rest is located over the workpiece, other auxiliary rests may be located bellow and over the workpiece. The design and optimizing of modular concept of the machines is based on long-term experience of our company with manufacturing of working machines. The design of machine corresponds to actual state of technique; the machine realization complies with the conditions of CE declaration.

Technical parameters
Swing diameter over bed1000 mm
Maximal machined diameter750 mm
Centre-to-centre distance2000 / 3000 / 4000 / 5000 / 6000 mm
Max. weight of workpiece3 t
Spindle endingA2-15
Bore128 mm
Speed range0,5-2 500 min-1
Main motor power (S1)71kW (55, 100)
Tailstock sleeve – swing / Ø180 / 220mm
Top rest120 (1:20) mm
Runs X/Y/Z782 / 210
acc. to length variant
Tool systemCAPTO C6
Maximal speed of tool spindle6 500 min-1
Tool spindle power (S1)29,3 kW
B axis swing+/- 102,5°
B axis indexingper 5°
Weight of basic variant 2000 mm42000 kg
