Press brakes Ermaksan

Share it:
- NewMachines.NET

Several pressbrake series: servo electric, hybrid, hydraulic

SERVO ELECTRIC

• 1.6 – 2 – 2.6 – 3 m length options
• 40 – 100 ton capacity
• Std. 6 axes – Y1, Y2, X, R, Z1, Z2
• CNC

HYBRID

• 2.6 – … – 4.27 m length options
• 100 – 260 ton capacity options
• Std. 6 axes – Y1, Y2, X, R, Z1, Z2
• CNC

HYDRAULIC

• 1 – 6 m length options
• 40 – 600 ton capacity
• axes 3 – 6
• CNC
• Tandem

Power bend Pro series

- NewMachines.NET

Standard equipment

Height adjustable and movable sliding front support arms.
Top and bottom tools are surface hardened by special treatment.
Promecam easy clamping system.
CYBELEC CYBTOUCH 12 PS 2D graphical controller with PC-ModEva 2D software.
CNC controlled strong X=800 mm back gauge
410 mm throat depth.
2 back gauge fingers
Scales in metric and inches.
Crowning system in bottom beam 3100/…/4100 – 260 – 320 manual crowning and from 400 tn and above motorized crowning is standard.
Foot pedal is produced according to CE standards and suitable for single and multiple bends.
2 photocells are placed facing each other for rear guards.
Covers for cylinders and top beam
Preadjusted electrical requirements based on customer’s geographical area.

Optional equipment

Special stroke and throat depth gives extra advantages for deep bends.
Delem ER70 controller (up to 5 axis).
Cybelec ModEva PAC Touch controller (up to 7 axis).
ER90Plus controller (3D touch screen).
Special back gauge fingers can be added on optional backgauge stroke.
Motorized crowning system.
Hydraulic oil heating and cooling.
Custom made table width and bottom tool V openings.
Optional top and bottom tools in different length.
Special tools for box and pole bends.
Laser front guard options.
WILA type top and bottom tool clamping system.
Rol1, 2, 3, 4, 5 different top and bottom quick release clamping systems.
Tooling cabinet mounted to side of the machine to keep your tools clean and in easy reach.
Automatic sliding system is lubricated automatically which is highly recommended to extend life.
U type special bottom tools for bending thick materials.
Additional front support arms to prevent waves on thin materials.
Custom made machines upon customer special parameters.
AP3 / AP4 front sheet support arms.
Special parking units for front support arms.
Electrical panel and / or controller can be mounted on right side of machine upon customer request.

Product inquiry contact

Click to see contacts

Phone: +90 224 294 75 44

Email: sales@ermaksan.com.tr

Complete product portfolio: Ermaksan
