CNC vertical machining center MC 1040 V
Travels XYZ 1040 x 540 x 600 mm
Table size: 1200×500 mm
CNC vertical machining center MC 1040 V is designed for machining of flat and box-type workpieces from all kinds of structural materials. Internal and external flat surfaces, round and irregular surfaces can be machined. The machine is determined for milling, drilling, finish boring, reaming and threading. The machine is equipped with digital drives and direct measuring with linear scales to achieve high accuracy during the machining of complex work pieces.
MAIN ADVANTAGES:
- Robust castings from grey cast iron for high rigidity achievement
- Wide working range at minimal floor plan
- Preloaded linear roller guideways guarantee high precision positioning of working axes
- Taper shank ISO 40 allows using of wide range of tooling
- Direct measuring HEIDENHAIN for all axes guarantees dimensions stability and repeatable accuracy of work pieces
- Laser calibration of a machine during assembly
- Control system and drives HEIDENHAIN
- Swivel control panel for comfortable machine control
- Electrocomponents from reputable European producers
- Zero loss grease lubrication of ball screws and linear roller guideways
- Watter proof covers with doors with glass widows
- Clamping table with five slots
- Design of the machine meets all safety standards and norms
- Wide range of optional equipment
CHARACTERISTIC FEATURES:
- Hand wheel HEIDENHAIN HR510
- Workpiece measurement touch probe HEIDENHAIN
- NC rotary table as 4th axis or as 4th and 5th axes
- External cooling of the cutting tools
- Chip conveyor left or right
- Zero loss grease lubrication
| Specifications | Unit | MC1040V |
|---|---|---|
| Working area | ||
| Table clamping surface | mm | 1200×500 |
| T slots number and width | mm | 5x18x100 |
| Max. workpiece weight | kg | 850 |
| Feeds | ||
| X axis | mm | 1040 |
| Y axis | mm | 540 |
| Z axis | mm | 600 |
| Spindle height from table surface | mm | 150-750 |
| Spindle | ||
| Taper shank | ISO 40 | |
| Spindle speed | min-1 | 12000 |
| Max. spindle torque (S6 – 25%) | Nm | 140 |
| Distance of spindle axis from column | mm | 570 |
| Spindle with ZF gear reducer – special execution | ||
| 1. step (1:4) spindle speed | min-1 | 20 ÷ 1600 |
| torque | Nm | 248 |
| 2. step (1:1) spindle speed | min-1 | 1600 ÷ 8000 |
| torque | Nm | 64 |
| Spindle drive | ||
| Main spindle motor (S1/S6 – 40%) | kW | 15/25 |
| Feed speed | ||
| Rapid traverse of X, Z , Y axes | m.min-1 | 30/30/25 |
| Working feed | m.min-1 | 0,001 ÷ 10 |
| Tool magazine | ||
| Number of tools | 24 | |
| Max. tool diameter at occupied surrounding magazine tool positions | mm | 100 |
| Max. tool diameter at free surrounding magazine tool positions | mm | 150 |
| Max. tool lenght | mm | 250 |
| Max. tool weight | kg | 6 |
| Positioning accuracy | ||
| X, Y, Z axes positioning accuracy | mm | 0,005 |
| X, Y, Z axes repeatable accuracy | mm | ± 0,0025 |
| Other | ||
| Coolant pump output | kW | 0,75 |
| Air pressure | MPa | 0,6 |
| Total machine input | kVA | 46 |
| Machine dimensions | ||
| Height | mm | 3100 |
| Width | mm | 3040 |
| Lenght with chip conveyor | mm | 4160 |
| Machine weight ( without equipment) | kg | 5600 |
| Control systems | ||
| CNC control system | HEIDENHAIN TNC 640 |
