Milling center FFC series specifications:
Working range: from 3000x1000x1200 mm up to 5000x1000x2000 mm
- Ram stroke 1200 mm
- Equipped with a floor plate and optionally with integrated rotary table
- Great offer of optional accessories and milling heads
- Automatic tool change up to 100 tools or with robotic tool change up to 189 tools
Milling center FFC is a highly-efficient machine allowing powerful and precise machining at every angle thanks to its stepless UHAmi milling head.
| Technical parameters | units | FFC 100 | FFC 120 |
| Spindle taper | SK 50 (ISO50) / BT50 / CAT50 / BIG+ | ||
| Spindle speed (max.) | rpm | 5000 | |
| Max. Power Heidenhain or SIEMENS CNC (S1/S6) | kW | 41 / 61,5; 53 / 77,9 | |
| Max. Torque Heidenhain or SIEMENS CNC (S1/S6) | Nm | 1230 / 1846; 1591 / 2338 | |
| X-axis Travel of Column | mm | 3000 / 4000 / 5000 | |
| Z-axis Vertical Travel of Ram | mm | 1200 / 1600 / 2000 | |
| Y-axis Horizontal Travel of Ram | mm | 1000 | 1200 |
| Rapid Feed X, Y | mm/min. | 30000, 30000 | |
| Rapid Feed Z | mm/min. | 30000 |
